A Quick Guide to JMeter PreProcessors

What are JMeter PreProcessors?



PreProcessors are JMeter elements that are used to execute actions before the sampler requests are executed in the test scenario. PreProcessors can be used for different performance testing needs, like fetching data from a database, setting a timeout between sampler execution or before test data generation. The options are plentiful and they are limited only by your imagination and your business needs.



This blog post will go over the 8 JMeter core PreProcessors: BeanShell PreProcessor, JSR223 PreProcessor, HTML Link Parser, HTTP URL Re-writing Modifier, JDBC PreProcessor, RegEx User Parameters, Sample Timeout and User Parameters.



BeanShell PreProcessor



Let’s assume we want to test a request that requires a “token” parameter. This parameter can be any random string. We could use a hardcoded string for all requests, but that would make our request less realistic than a real-life scenario, since tokens are not the same for all users and workflows.



This is a great example of when we can easily use a PreProcessor to generate a random string and to use it in a sampler. The BeanShell preprocessor is suitable for this since it enables managing any programmer task in your performance scripts, if you are familiar with Java programming language. BeanShell is a lightweight scripting language that has Java-like syntax.



To add the BeanShell PreProcessor to the Sampler request:



Right Click on the Sampler -> Add -> Pre Processors -> BeanShell PreProcessor



jmeter beanshell preprocessor



BeanShell PreProcessor configs:

  • Name - the name of the sampler shown in the Thread Group tree
  • Reset bsh.Interpreter before each call - Resets the interpreter before each call and cleans occupied memory. Setting this option as “True” might be useful for long running scripts, since repeated invocations might consume a lot of memory
  • Parameters - JMeter parameters that will be passed to the BeanShell script. You need to keep in mind that you cannot use JMeter variables in the BeanShell preprocessor if they are not specified in this configuration field. If a parameter is specified, you can use it in the preprocessor like this:
String BS_Variable_Name = vars.get("JMeterVariable");
  • File Name - the path to an external BeanShell script that needs to be run



The BeanShell preprocessor script might be external or internal. If it’s internal, you can write it into the “Script” field of the BeanShell Preprocessor. In any other case, you need to use the ‘File Name’ configuration field. To generate a random string, you can use this simple code example:



import java.util.Random;

chars = "1234567890abcdefghiklmnopqrstuvwxyz-";
int string_length = 36;
randomstring ="";

for (int i=0; i < string_length; i++) {
  Random randomGenerator = new Random();
  int randomInt = randomGenerator.nextInt(chars.length());
  randomstring += chars.substring(randomInt,randomInt+1);
}
print(randomstring);
vars.put("RANDOM_STRING",randomstring);



The Result “BeanShell PreProcessor”:



jmeter beanshell preprocessor



With the PreProcessor in place, you can now use the random script you created in your sampler:



jmeter beanshell preprocessor



Now, if you add a listener and verify a send request, you will see that your request will contain a unique token.



jmeter beanshell preprocessor



Click here for more detailed BeanShell preprocessor examples.



JSR223 PreProcessor



The JSR223 PreProcessor is another way of scripting by using PreProcessors. JSR223 has similar functionality to the BeanShell preprocessor. The main difference from BeanShell is that you can use additional scripting languages: ecmascript, groovy, java, javascript, jexl and nashorn.



With the JSR223 preprocessor you need to make sure that your script does not use JMeter variables directly in the script code, as there is a caching mechanism that will only cache the first replacement and all next variable updates will not be available in preprocessor at all.



To add the BeanShell PreProcessor to Sampler request:



Right Click on the Sampler -> Add -> Pre Processors -> JSR223 PreProcessor



To show the JSR223 preprocessor in action we can rewrite the previously created script for a random string creation which we used with BeanShell. This time we will use JavaScript.



function generateRandom() {
    var text = "";
    var possible = "ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789";

    for( var i=0; i < 36; i++ )
        text += possible.charAt(Math.floor(Math.random() * possible.length));

    return text;
}

var random = generateRandom();
vars.put("RANDOM_STRING", random);



jmeter jsr2233 preprocessor



We recommend using Groovy with the JSR223 PreProcessor.



HTML Link Parser



The HTML Link Parser PreProcessor can be used to parse a response, extract all the found links and request them further. This can be useful when the main goal of your script is to simulate web crawling.



First of all add a basic request to your home page.



jmeter html link parser preprocessor



After that, add a controller. The Simple controller can be used to make a random request using a link from a previous sampler response, and the While controller with a condition can be used for crawling all links.



The next step is to add a Sampler that will limit the scope of crawled pages.



jmeter html link parser preprocessor



As a last step, add the “HTML Link Parser”:



Right Click on the Sampler -> Add -> Pre Processors -> HTML Link parser



jmeter html link parser preprocessor



When you run your script, you will see that JMeter parsed response from the initial request and crawled all the links it found:



jmeter, HTML Link Parser preprocessor



Please note this preprocessor is less popular than the others.



HTTP URL Re-writing Modifier



The HTTP URL Re-writing Modifier PreProcessor can be used if your application uses URL rewriting in order to store a connection session. Briefly, it allows your script to find a session id parameter on a page and add that parameter to all the requests in its scope.



To add the Re-writing Modifier:



Right Click on the Sampler -> Add -> Pre Processors -> HTTP URL Re-writing Modified



jmeter html url re-writing modifier



HTTP URL PreProcessor configs:

  • Name - the name of the element in the Thread group
  • Session Argument Name - the parameter name that will be parsed from the response and used as a substitution in all further requests
  • Path Extension - should be checked in case your application rewrites URLs by appending a semi-colon with the session parameter.
  • Do not use equals in path extension - should be checked if your application rewrites URLs without the “=” sign between the parameter name and value
  • Do not use questionmark in path extension - should be checked if your application needs to prevent query strings from ending up in the path extension
  • Cache Session Id - should be checked in case your application requires a session Id for later use when the session Id is not present
  • URL Encode URL Encode - should be checked if your application needs encoded URLs



Now, all you need to do is to enter the name of the session ID into the ‘Session Argument Name’ field. If it’s found, it will be added to all further requests. If further requests already have session ID values, then these values will be replaced.



Please note this preprocessor is less popular than the others.



JDBC PreProcessor



By using the JDBC PreProcessor, you can run SQL statements right before your sampler. JDBC is an application programming interface that defines how a client can access a database.



Let’s assume that we have a login workflow that contains a user email and password as request params.



jmeter jdbc preprocessor



You can keep these test values in the sampler itself, but that would be very inefficient, since each time your user updates their email or password, you would have to update your script accordingly. This is a great example of when you can substitute hardcoded parameters with dynamic values fetched from database.



First of all, we need to make a proper configuration of the JDBC driver for your database. After that, add the JDBC PreProcessor:



Right Click on the Sampler -> Add -> Pre Processors -> JDBC PreProcessor



jmeter, jdbc preprocessor



JDBC PreProcessor configs:

  • Name - the name of sampler shown in the JMeter tree
  • Variable name - the name of the connection pool (specified in JDBC Connection Configuration)
  • Query type - all commonly used statement types (for example, you can not use select type if your query updates db values)
  • SQL Query - the SQL query itself (without a trailing semi-colon)
  • Parameter values - a list of comma-separated parameters if the SQL query is parameterized
  • Parameter types - a list of comma-separated SQL parameter types (see more about supported types here: Javadoc for java.sql.Types)
  • Variable Names - a list of comma-separated variables to keep fetched database data values which are returned from database
  • Result Variable Name - key-values variable containing a returned dataset
  • Query timeout (s) - max seconds of results querying
  • Handle ResultSet - specify how query results should be handled



In our case, we can just specify the Select Statement to retrieve the required data from the database.



jmeter, jdbc preprocessor



After that, we can substitute the input parameters with dynamically fetched data:



jmeter, jdbc preprocessor



RegEx User Parameters PreProcessor



The RegEx User Parameters PreProcessor should be used in combination with the Regular Expression Extractor PostProcessor. It allows you to use dynamic values for the HTTP request that have been extracted from another HTTP sampler. With this component you can use extracted names and values of different parameters in response to the previous request.



Let’s assume we have the first http request which returns the response body with this kind of html:



……..
<div class=’parameters’>
    <input name=’username’ value=’TestUser’>
    <input name=’password’ value=’Test123!’>
<div class=’parameters’>
……..



We see that all parameters contain names and values. In this case we can make a generic regex to extract all variables including name and appropriate value which will be separated using regex groups (round brackets):



jmeter, RegEx User Parameters PreProcessor



Based on the specified regex, we see that ‘listParams’ reference will contain all variables parsed from first request. Group 1 of that regexp will return names while group 2 will return the appropriate value. In this case we can specify RegEx User Parameters configuration this way:



jmeter, regex user parameters preprocessor



With this configuration, our second http request will take all the parameters from the listParams reference and use them as request parameters. In other words: RegEx User Parameters help to parse list of parameters form the http request and easily apply these parameters in next request.



Sample Timeout PreProcessor



The Sample Timeout PreProcessor specifies the max time execution for the specified sampler. If the sampler execution takes too long, it will be interrupted.



To add the Sample Timeout preprocessor to the Sampler request:



Right Click on the Sampler -> Add -> PreProcessors -> Sample Timeout



jmeter sample timeout preprocessor



Please note that only the following samplers support this interaction: AJP, BeanShell, FTP, HTTP, Soap, AccessLog, MailReader, JMS Subscriber, TCPSampler, TestAction, JavaSampler.



Based on JMeter documentation, this sampler is marked as “BETA CODE - the test element may be moved or replaced in a future release”. You need to keep this in mind if you usually upgrade your JMeter with new versions.



User Parameters PreProcessor



The User Parameters PreProcessor specifies user input parameters specific to individual threads. For each thread, the variable value will be used based on the order of that user thread in sequence.



jmeter user parameters preprocessor



If you want to update variables using only one iteration and to make sure the values are updated each time based on the execution of the parent controller, you need to check the “Update Once Per Iteration” checkbox.



In general, this preprocessor is one option for parameterizing your requests. But usually, csv data set configuration element provides more flexibility for parameterization. Check this article right here to see details.



Congratulations! You now have basic knowledge of JMeter’s core processors. Want to learn more JMeter? Check out this free 5 day online course. To learn about BlazeMeter, request a demo or start testing for free - put your URL or JMX file in the box at the top of this page and your test will start in minutes.
